Flexible Pavement Design for Irish Ground Conditions in Celbridge

For a site up to 2,000 square metres, such as a small apartment block car park or a single cul-de-sac, a complete flexible pavement design package typically falls between €1,340 and €4,190. The final figure depends on the number of trial pits required, the extent of laboratory testing needed, and whether the local authority requests a formal design certification for taking-in-charge.

The current TII method, set out in DN-PAV-03023, uses a mechanistic-empirical framework where the critical strains in the asphalt (fatigue) and the subgrade (rutting) are calculated directly from layer moduli and Poisson's ratios. The older HD 26/06 relied on a catalogue of pre-approved sections tied to CBR and traffic class. The TII approach is more material-efficient because it accounts for the actual stiffness of each layer rather than assuming conservative default values.

No frost protection layer is required by TII standards for County Kildare. The frost index for the Celbridge area is below 50 degree-days, which means the depth of frost penetration in a typical winter does not reach the depth where it would cause differential heave in the subgrade. We confirm this in every design report with a frost susceptibility check on the formation soil, but in practice it is never the governing design condition here.

Under TII DN-PAV-03023, a capping layer is required when the in-situ subgrade CBR at formation level is below 5% after a four-day soaked test. Between 2.5% and 5% CBR, we can use a geogrid-stabilized granular capping to bridge the weak soil. Below 2.5% CBR, which we have encountered in the made ground deposits in parts of Celbridge, the pavement design must include either a lime-stabilized capping layer or a thicker granular platform designed with a separator geotextile to prevent contamination of the stone by the soft subgrade.
